Miller Migmatic 380 Compact Mig Welder 400V 3 Phase

Calculating latest stock
Code: 12205
Part No: MIGMATIC380
Order For Delivery
Select the required delivery time and method at checkout.
Allow 4-5 days for delivery
Click & Collect
Check the stock levels at our depots below and select ‘Click and Collect’ at checkout (where available).
Check the stock at each depot:
View depots
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
£1,898.82 each
exc. VAT
£2,278.58 each
inc. VAT
Add to order

Product Overview

Manufacturer: Miller

  • The Miller Migmatic 380 is an industrial step transformer compact MIG which offers superior welding characteristics due to the modern transformer design, excellent starting and a very stable welding arc make it suitable for a wide range of industrial applications.


    Digital meters shows current, voltage or wire feed speed, simply choose the preferred readout by pushing the selector button.

    30 voltage steps enough for precise adjustment of the welding voltage.

    Adjustable run- In and burnback allows the user to optimise arc starts & stops, reducing wire stubbing or wire burning back onto the contact tip.

    Thermal Protection with indicator light, prevents damage when there is a risk of overheating, due to over duty cycle or reduced airflow.

    2-4 Step trigger mode with gas preflow and post flow function in 4 step mode, for ease of use during long welds.

    Built-in spot-weld feature provides consistent timed welds.

    Miller industrial 4 roll driven wire drive.

    Two choke connections for optimal inductance for the most common applications.

    Factory fitted running gear and cylinder rack.


    Input Power: 3-Phase, 400VAC, 50Hz

    Rated Output: 350A @ 35% Duty Cycle

    30 Voltage steps

    Wire Feed Speed, 2 – 26 m/min

    Dimensions (H x W x D): 825 x 471 x 1066mm

    Weight: 103kg

    Supplied with: Ground cable, Power cord (without plug) Drive roll kit 1.0 / 1.2mm / V-groove.

    Mig torch and Regulator sold separately to suit application.
