Weco WF107 Detachable Wire Feeder 4 Roll Drive

Calculating latest stock
Code: 12078
Part No: 00103230000WEC
Order For Delivery
Select the required delivery time and method at checkout.
Allow 1-2 days for delivery
Click & Collect
Check the stock levels at our depots below and select ‘Click and Collect’ at checkout (where available).
Check the stock at each depot:
View depots
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
£1,398.36 each
exc. VAT
£1,678.03 each
inc. VAT
Add to order

Product Overview

Manufacturer: Weco

  • The Weco WF107 wire feeder is a detachable 4 roll wire feed unit used with the Weco Pioneer 321MSR and 401MSR invertor power sources. The WF107 offers the choice of Manual and Synergic MIG/MAG.


    4 Roll wire feed system with adjustable wire feed pressure to ensure uninterrupted wire feeding on a variety of wire types.

    Pre and Post gas delivery for before the welding arc is created and after the welding arc is extinguished, creating in an uncontaminated atmosphere, this is useful when welding at high current values or with materials that oxidise readily when the weld pool cools.

    Gas flow adjustment button opens the gas solenoid valve to fill the circuit and calibrate the pressure with the regulator and flow meter on the gas cylinder.

    Various torch trigger selections are available to ensure the best possible results on more difficult to perform processes.

    Personalised welding settings, or jobs can be stored in the memory locations and can subsequently be uploaded when required, up to 99 jobs can be saved. This function is unrivalled when application repeatability is required and set welding parameters need to be achieved.

    Locking facility, this procedure inhibits unit adjustments, allowing the user to modify only certain settings depending on the selected lock status, this prevents accidental alteration of the welding settings by the operator, helps to set welding parameters.

    Euro adaptor connector for MIG/MAG torch.


    Supply voltage: 48 V A.C.

    Work cycle 450amp @ 60 %

    Welding current 450 Amp

    MIG/MAG welding voltage: 14.2 V – 29.0 V

    Maximum gas pressure: 0,5 MPa (5 bar)

    Motor speed: 1.5 – 22.0 m/min

    Maximum Wire spool: (dimensions/weight) 300 mm / 15 kg

    Dimensions ( L x D x H ): 245 x 670 x 470 mm

    Protection rating IP23

    Construction standards EN 60974-5, EN 60974-10 Class A

    Weight: 21.5 kg
