Mafell NFU50 Birds Mouth Groove Cutting Machine

Calculating latest stock
Code: 34402
Part No: NFU50240MAF
Order For Delivery
Select the required delivery time and method at checkout.
Allow 2-3 days for delivery
Click & Collect
Check the stock levels at our depots below and select ‘Click and Collect’ at checkout (where available).
Check the stock at each depot:
View depots
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
0 in stock
Out of stock
£1,795.00 each
exc. VAT
£2,154.00 each
inc. VAT
Add to order

Product Overview

Manufacturer: Mafell

  • The Mafell NFU50 Birds Mouth Groove Cutting Machine offers flexibility of use and is an all-rounder capable of executing on enormous range of timber construction tasks.


    The design of the NFU 50 is characterised using extremely rugged, high-quality, and precision-made parts, including the lightweight magnesium die-cast housing and impact-resistant, fibre glass-reinforced plastic components. It also features clever technical details to help you meet the rigors of the job.

    The rotating 58 mm (2 5/16”) hose connector for large volumes of dust can be positioned by means of a locking function.

    The 2-in-1 functionality allows the cutting depth to be set quickly and easily.

    The hydraulic brake stops the tool within 3 seconds. The flashing LED lamp indicates to the user that the cutter is still turning.

    The NFU can be removed from the cross-cut track at the single press of a button, allowing its use either freehand or on the guide rail.


    Lengthwise and crosswise grooves.

    Frieze blocks (With guide).

    Panels in half-timbered buildings, false floors.

    Angled grooves up to 45°.


    Compatible materials include solid wood and board materials.


    Voltage: 230V

    Input: 2300W

    Cutting depth at 0° without guide track: 0 – 50 mm

    Cutting depth at 0° with guide track: 0 – 44 mm

    Tilt range: 0 – 45 °

    No. of strokes: 5900 1/min

    Dimensions (W x L x H): 370 x 810 x 280 mm

    Cutting length with guide: 370 mm

    Weight: 9.4 kg

    Included as Standard:  Cutter Head Ø 163 x 60 mm, Position Indicator, Side Fence, Parallel Fence, Guide Track, 2 x Repeat Fences, Allen Key, Screwdriver Torx & 10m Mains Cable.

    3 Years Warranty on all Mafell Power Tools when registered.
